LAST DOSE NUT

Feeding group for last dose nut (components for insulin dosing device)

Description

Feeding group for LAST DOSE NUT composed of 2 electroresonant bowl feeders, 5 electroresonant linear feeders and a pacing selector.

Technical data

Speed (pieces/hour) 17.280
Components to be assembled 1
Product Versions 1

Ready to Run

Start-up time 2 days
Ramp-up time 1 hour
Feeding group for last dose nut (components for insulin dosing device) LAST DOSE NUT

Characteristics

Main features
Use of high-frequency Electroresonant Feeders with piezo-electrical system built by the company Moxmec; this allows a regular and constant flux of feeding, reduced dimensions and inferior power consumption than the electromagnetic system.

The bowl feeders are arranged to feed continuously the pieces one after the other with the open side facing the interior of the bowl. The piece is guided on the circumference and on the two hedges. Bowls and grooves are made of stainless steel and CNC working to guarantee high precision. Pacing selector to pace 6 plastic pieces contemporarily.
